Product Name: ½.7’’ 1080P 0.01 lux Night Vision USB Infrared Camera
Product Advantage
1, 1080P FHD Night Vision USB Webcam suit for multifunctional application, pluy and play
2, 10pcs small infrared Light LED to enhance and improve perfect night vision possibility
3, lowest 0.01 low lux low light OV chipset insure one wonderful Night Vision USB Camera
4, Widely used in portable CCTV Camera System, Industrial Monitoring and embedded version system camera
Product Specifications Of 1080P USB IR Camera
|
Product Name |
3.7mm USB Night Vision CCTV Camera |
|
Cmos Sensor |
½.7 inch OV2710 cmos 0.01 low lux |
|
Video Resolution |
1920X1080, 1080P@30fps |
|
Lens FOV |
DFOV 102degree, HFOV 92degree |
|
Photo Pixel |
2 Megapixels |
|
Photo Format |
MJPG |
|
video output |
MJPG/YUY2// RGB24 |
|
Lens Focal Length EFL |
3.7mm standard cctv lens m12 |
|
Lens Construction |
2MP 1G3P |
|
F/No Aperture |
F2.0 |
|
AGC |
OSD |
|
Minimum illumination |
0.01LUX |
|
S/N Ratio |
≥52dB |
|
Gammar |
0.45 |
|
Backlight Compensation |
OSD |
|
Shutter |
30f/s |
|
White balance |
Auto |
|
Working temperature |
-10~+50℃ |
|
Power |
5V |
|
Audio Microphone |
Support, |
|
System Sync |
inner Sync |
|
Power consumption |
150mA |
|
Product Size |
34*34*20mm |
|
Signal Type & Interface |
usb 2.0 interface, digital Signal |
|
Length of Cable |
3Meter ( 1m/5m/other length available custom made) |
|
Certificated |
UL/USB-IF/WHQL/CE /ROHS |
|
standard |
Follow UVC standard |
|
Default Property |
Brightness contrast saturation ,hue sharpness ,white balance, game exposure controlled |
|
System |
WIN10/WIN7/WIN8/Linux/Android/Apple Mac |
Note & Remarks
1, We can adjust other size USB case to meet your special demand
2, We can adjust USB cable Length or change it with foldable Pipe (shorter size)
3, its Interface connector can be changed or custom by Network, BNC/AHD, OTG Type C etc
4, we can exchange or equip other focal length 2.1mm, 1.05mm,2.8mm, 3.2mm, 6mm, 4mm, 8mm, 12mm, 16mm,21mm, 25mm, 2.3mm low distortion 120 degree, and 4.6mm non-distortion lens, 185/195/200/210/220 Degree Fisheye Lens to meet your more special requirements.
Product Application of Night USB Camera
1, Portable Warehouse/office/home/apartment/commercial/industrial CCTV Security
2, Self service terminals equipment, Automatic Vending Machines Security
3, Telecommunications, supermarkets, hotels, public security
4, Justice, prisons, School, ATM Machine, Traditional Security
5, Big Machines or Equipment Device that need built-in good Night Vision Camera with infrared light
Customize USB Cameras
Currently we can provide more than 20 models USB Camera for various commercial / industrial applications, our camera with DIY interchangeable Lens design. We also welcome any unique requests. R&D, Molding, development, prototyping, and mass production are offered at reasonable prices and in-time Fast Delivery. Our team work closely with each customer to assure satisfaction from start to finish. Customization options include, but are not limited to:
Specific image Cmos sensor requirements, WDR, panoramic or Wide Angle, expected Product Dimension, Dual lens, low-light low lux capturing, Lens MTF Resolution(1.3/2/3/4/5/6/8/10/12MP), Auto Focus USB Module, infrared IR solutions, high or low temperature rated, Waterproof, weatherproof, different angles of view, wire harness, cable assembly, desired power voltage, resolutions, frame rate, various USB port, etc. welcome to send us your technical drawing/diagram or share any new idea with us together for evaluation
At last, we are open to discuss any new idea or request regarding creative embedded usb camera and industrial usb camera modules with you in anytime, encourage you to view our more online products and give us your feedback or comments or advice for our usb
P.S. We supply Sony CCD Camera and Andriod OTG Camera for mobile Phone too
