Product Name: 220 degree Panoramic USB Camera with interchangeable lens design available
Product Advantage
1, Horizontal 200 degree Super Wide Angle Fisheye Image and Video
2, 1080P FHD Video output and connect with any device with USB interface
3, 0.01Low lux, low light starlight Cmos sensor insure good night vision too
4, Mini Usb Camera with Interchangeable lens available design to extend
More various commercial and industrial Application too
5, Compact Mini Design, Free drive, Plug and play, Hands free filming
6, Can change into Type-C, USB Micro, AHD/BNC Analog Signal interface
Product Specifications Of 220 degree China Fisheye USB Camera
|
Product Name |
Low Lux Fisheye Lens USB Camera |
|
Cmos Sensor |
GalaxyCore ½.9 inch cmos low lux |
|
Video Resolution |
1920X1080, 1080P@30fps |
|
Lens FOV |
220 degree Super Fisheye Lens |
|
Photo Pixel |
2Megapixels |
|
Photo Format |
MJPG |
|
video output |
MJPG/YUY2 |
|
Lens Focal Length EFL |
1.47mm 220° Fish eye |
|
Lens Construction |
6G+IR |
|
F/No Aperture |
F2.0 |
|
AGC |
OSD |
|
Minimum illumination |
0.01 LUX |
|
S/N Ratio |
≥52dB |
|
Gammar |
0.45 |
|
Backlight Compensation |
OSD |
|
Shutter |
30f/s |
|
White balance |
Auto |
|
Working temperature |
-10~+50℃ |
|
Power |
5V |
|
Audio Microphone |
Built in Microphone, Support |
|
System Sync |
internal |
|
Power consumption |
150mA |
|
Product Size |
15*15*10mm |
|
Signal Type & Interface |
usb 2.0 interface, digital Signal |
|
Length of Cable |
3 Meter （standard）1m or other size available |
|
System |
WIN10/WIN7/WIN8/Linux/Android/Apple Mac |
Actual photo took by 200 degree Fisheye Lens USB Camera 1080P in December, 2020
Note & Remarks
1, You can change our other focal length M12 board lens include but not only 3.7mm pinhole, 2.1mm wide angle, 2.8mm lens,
16mm Telephoto, 25mm Telephoto, 5MP CCTV Lens,Low distortion Lens, No distortion Lens, 1mm wider Fisheye Lens,
Black light F1.0 Lens,4mm/6mm/8mm security lens, button Lens etc to meet your special requirement of projects
2, We can change standard USB cable into foldable adjustable Pipe (shorter length)
3, its Interface connector can be changed or custom by USB Micro, BNC/AHD, OTG Type C etc
4, You are kindly advised to equip 2-3pcs various focal length Lens to meet various application together in your order, then
you can interchange various lens freely locally, no need buy more cameras more at higher cost again
Actual video screenshot took by 180 degree Fisheye Lens 1080P USB Camera in December, 2020
Product Application
1. Inspecting industrial Equipments/machines/device (Machine Vision)
2. Vehicle and boat control, electronic equipment, oil field equipment/machine,
remote control monitoring, Forest Monitoring, environmental monitoring, etc.
3. Wide Angle USB Security Camera, Panoramic USB Camera for CCTV
