Product name: Aftermarket RearView Reversing Camera with 4Pin RCA for Mercedes Benz Sprinter 12V
IP67 Waterproof PAL/NTSC CVBS Parking Camera For Mercedes Benz Sprinter
Product Feature of Backup Camera For Mercedes Sprinter
1,Imported cmos chips, high-definition image color, more realistic
2,170°wide angle viewing, safer reversing
3,With a reverse reference line (electronic ruler line), the obstacle distance is clear at a glance.
4,Digital sensor chip processing, night vision effect is obvious.
5,Multi-layer waterproof design, truly high pressure washing and soaking waterproof.
6,Installed at the rear handle and license plate lights, with screws and washers.
7,The video cable is connected to the monitor, the power cable is connected to the car taillight power supply, and the reverse monitoring system is used when reversing.
8,Start work automatically, you can clearly see the situation behind the car
9, Provides monitoring of the environment inside and outside the car to provide safety for the vehicle
Product Specification of Mercedes Benz Reversing Camera
Lens Angel: 170°
Rated Voltage: 9-36V
Power: 1W
Video Color: Colorful
Video Output: 1.0Vp-p，75 ohm
Waterproof: IP67 - IP68
Video System: NTSC
SNR: ≥48dB
Image: Mirror
Min Illumination: 0.1LUX (with 9 IR lights)
Resolution: 600 TV Line
Working Temterpure: -20°C + 70°C
Store Temterpure: -40℃ + 85℃
Shell Material: Metal
Body Color: Black
Applicable Models: Universal but specially designed for Mercedes Benz Sprinter
Backup Camera Interface: backup camera installed medias or screens with RCA/4pin video input only, it is NOT for original Car media directly!You can add camera interface or adapter cable if want to use it with original media.
Night vision&Waterproof: 12 IR LEDs with light sensor for night mode which you can see clear in the dark,IP68 grade ensure long life time and stable work for years.
The compact color camera is built into the body of the third tailight housing.Installation is a simple matter of removing the exisitng third tailight and replacing it with the new unit. You will need to run the included wire harness and make connections and you are done.
Package Included:
1 x Car backup Camera for Mercedes Benz Sprinter
1 x AV Cable
1 x Power Cable
Note:
-Please allow 1-10mm difference due to manual measurement.
-Due to light and screen difference, the item's color may be slightly different from the pictures.
Product Application
The backup camera is suitable for Mercedes-Benz Sprinter/Volkswagen Crafter with original factory size. you can use directly without extra installation hole.
this Aftermarket Backup Camera also can work and apply For Passenger Bus, School Bus, City Bus, Travel bus, Coach bus,Sightseeing Bus, Airport shuttle, Autobus, Double Decker Bus, Tourist Bus,Tourist Coach
